Descripción
Kingston FURY KF560C36BBE2A-16 is a 2G x 64-bit (16GB)
DDR5-6000 CL36 SDRAM (Synchronous DRAM) 1Rx8, memory
module, based on eight 2G x 8-bit FBGA components per module.
The module supports AMD® EXPO v1.1 and Intel® Extreme
Memory Profiles (Intel® XMP) 3.0. Each module has been
tested to run at DDR5-6000 at a low latency timing of 36-44-44 at
1.35V. The SPDs are programmed to JEDEC standard latency
DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM
uses gold contact fingers. The JEDEC standard electrical
and mechanical specifications are as follows:
