Descripción

General
Standards
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x flow control
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3az EEE power saving
Switching Fabric
• 1 Gbps switching fabric
Topology
• Star
Protocol
• CSMA/CD
Data Transfer Rates
• Ethernet
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
• Fast Ethernet
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
Media Interface Exchange
• Auto MDI/MDIX adjustment for all ports
Network Cables
• 10BASE-T:
• UTP CAT 3/4/5/5e (100 m max.)
• EIA/TIA-586 100-ohm STP (100 m max.)
• 100BASE-TX
• UTP CAT 5/5e (100 m max.)
• EIA/TIA-568 100-ohm STP (100 m max.)
LED Indicators
• Per port: Link/Activity
• Per device: Power
Transmission Method
• Store-and-forward
MAC Address Table
• 2K entries per device
MAC Address Learning
• Automatic update
Packet Filtering/Forwarding Rates
• Ethernet: 14,880 pps per port
• Fast Ethernet: 148,800 pps per port
RAM Buffer
• 48 KB per device
