Descripción

P/N PS-TPD-750FNFAGx-H
WATTS 750W
MODELO TTP-750AH2FKG
MAX. OUTPUT CAPACITY 750W
COLOR Black
DIMENSION ( W / H / D ) 150mm(W)x86mm(H)x140mm(D)
PFC (POWER FACTOR CORRECTION) Active PFC
POWER GOOD SIGNAL 100-250 msec
HOLD UP TIME > 17msec
INPUT CURRENT 10A Max.
INPUT FREQUENCY RANGE 50Hz – 60Hz
INPUT VOLTAGE 100 – 240Vac
OPERATING TEMPERATURE 0°C to + 45°C
OPERATING HUMIDITY 5% to 85%,non-condensing
STORAGE TEMPERATURE -40°C to + 70°C
STORAGE HUMIDITY 5% to 95%, non-condensing
SISTEMA DE REFRIGERACIÓN 12cm FDB Fan
EFFICIENCY Meet 80 PLUS® Gold at 115Vac input.
MTBF 100,000 hrs minimum
SAFETY APPROVAL CE/FCC/UKCA/ICES/LVD/TUV/cTUVus
/CB/CCC/BSMI
PCI-E 6+2PIN 4
PCIE 12+4PIN 1(300W)
